GPI offer a range of gear and vane drum pumps, these pumps mainly are suitable for diesel, kerosene and petroleum. Most of GPI’s pumps are either hand operated or AC/DC 12v or 24v although they do offer 1 or 2 230v pumps and dispensing systems. They do also offer an extensive range of flow meters.
Hand Pumps
HP100 Lever Hand Pump
The HP-100 Duel Flow Hand Pump is a premium hand pump that is reliable and versatile. Suitable for high volume fuel transfer (use the high handle position), the HP-100 generates twice the flow of any other hand pump.
Flow Rate: 1.9L per stroke cycle
Fitting Size Inlet – 1″ NPT
Fitting Size Outlet: 3/4″ NPT
Tank Adaptor: 2″ NPT
Wetted Parts (Body) – Aluminium
Wetted Parts (Seals) – Buna-N (Nitrile)
Wetted Parts (Liner) – 316 Stainless Steel
Hose Dia – 3/4″
Hose Length: 2.4m – 8ft
Hose Material: Buna-N
Nozzle: Thermoplastic, unleaded
Adjustable Suction Pipe: 22″ – 40″ or 55cm – 100cm
HP90 Lever Hand Pump
The HP-90 is an economy hand pump with a dual-action piston to pump fluid on both the push and pull strokes for fast fueling. This reliable hand pump is compatible with a wide variety of fuel products: Diesel fuel (biodiesel blends B20), Gasoline (alcohol blends E15), Kerosene and up to 15 weight oil.
Flow Rate: Up to 25 gallons per 100 strokes
Inlet Port: 1″ NPT
Outlet Port: 3/4″ NPT
Hose: 3/4″ x 8ft Buna-N Hose
Nozzle: Thermoplastic unleaded nozzle
Suction Pipe: 2 Piece PVC
Construction: Aluminium Housing, SS Shaft, Plastic Piston
